HD-P008 Sheet Former for Paper Compression and Burst Testing

HD-P008 Sheet Former for Paper Compression and Burst Testing
HD-P008 Sheet Former for Paper Compression and Burst Testing HD-P008 Sheet Former for Paper Compression and Burst Testing HD-P008 Sheet Former for Paper Compression and Burst Testing

Hình ảnh lớn :  HD-P008 Sheet Former for Paper Compression and Burst Testing

Thông tin chi tiết sản phẩm:
Place of Origin: China
Hàng hiệu: Haida
Chứng nhận: CE、ISO
Model Number: HD-P008
Thanh toán:
Minimum Order Quantity: 1 set
Giá bán: Có thể đàm phán
Packaging Details: each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 300 Sets per Month

HD-P008 Sheet Former for Paper Compression and Burst Testing

Sự miêu tả
Chức năng: Kiểm tra nén, kiểm tra cường độ nén ống giấy, thử nghiệm nổ, kiểm tra độ bền kéo, dụng cụ kiểm tra g Tên: Máy kiểm tra cường độ nén ống giấy, dụng cụ kiểm tra giấy GSM TEST/ TESTER SỨC KHỎE, Dụng cụ kiểm tr
Trưng bày: LCD, hiển thị kỹ thuật số Tính năng: Dễ dàng vận hành
Phương pháp hoạt động: Tự động Loại sản phẩm: Công cụ kiểm tra
Thiết bị bảo vệ: Thiết bị bảo vệ loại cảm ứng Điều khiển: Kiểm soát PLC
Phương pháp cảm biến: Máy phát áp suất Dừng lại: Dừng kiểm tra
Độ phân giải lực: 1/500000 lực kiểm tra tối đa FS Chế độ rung: đáp lại
Cài đặt chu kỳ kiểm tra: 4 chữ số bộ đếm sẵn
Làm nổi bật:

Burst Testing Paper Sheet Former

,

Paper Compression Sheet Former

,

Paper Sheet Former

EQUIPMENT DETAILS OF HD-P008 SHEET FORMER
HD-P008 Sheet Former for Paper Compression and Burst Testing 0
Product Attributes
Attribute Value
Function Compression test, Paper Tube Compressive Strength Test, Burst tester, Tensile test, Paper Testing Instrument
Name Paper cup tube compressive strength tester, Paper testing instrument paper gsm tester/bursting strength tester, Paper testing instrument
Display LCD, Digital display
Feature Easy to operate
Operation Method Automatic
Product Type Testing Instruments
Protection Device Induction type protection device
Control PLC control
Sensing Method Pressure Transmitter
Stop Stop test
Force Resolution 1/500000 of the maximum test force fs
Vibration Mode Reciprocating
Test Cycles Setting 4 digits pre-set counter
Application

This instrument complies with ISO5269/2 "Pulp - Preparation of Laboratory Paper for Physical Testing" Part II - Rapid Sheet Forming Method. It is used to prepare handsheets for testing physical properties and can also be used for wet sheeting of various fibers including glass fibers, carbon fibers, and nanomaterials. The machine integrates sheet copying, suction filtration, pressing, and drying functions, enabling the complete process from fiber to sample shaping on a single unit.

Standard Features
Inner diameter of round type pulp storage container ≥ 200mm
Water filtering copper mesh surface to water seal overflow edge 800+5mm
Water filtering copper mesh pressure hole (80 .100) optional (nano-fiber using the way of the tray network + filter paper)
Copper mesh clip material 304 stainless steel Copper mesh material: paper special phosphorus copper mesh
Volt weight 13kg hand-copied paper sheet pressure of 400kpa (volt roller press can increase the smoothness and uniformity of the paper)
Diameter of hand-copied paper sheet ∮200mm
Vacuum pump vacuum degree -0.092~-0.098MPa
Vacuum pressing force ≈0.1MPa
Drying station 1 (2 or more stations can be optioned)
Drying temperature ≤140℃ Digital arbitrary setting
Drying plate release mode Natural release (with self-absorbing function automatically absorbing after pressing together)
Drying time (quantitative 10-85g/m2) 3-6 minutes (varies for different fiber types with different moisture content of paper samples)
Heating power 2.5KW
Paper thickness range 10-200g/m2 0.05-3mm (varies for different fiber types)
Seal ring material Silicone
Water way Bottom water. The upper end of the water
Drainage method Pneumatic water release
HD-P008 Sheet Former for Paper Compression and Burst Testing 1
HD-P008 Sheet Former for Paper Compression and Burst Testing 2
HD-P008 Sheet Former for Paper Compression and Burst Testing 3
